ISO 03: On A and B with cross pilot / T-11A
NINETY DEGREE BODY / T-11A / SAE 6
FITTING, AIR, UNION TEE, 6MM
FITTING, AIR, UNION TEE, 8MM
FITTING, AIR, UNION TEE, 12MM
FITTING, AIR, STRAIGHT MALE CONNECTOR, 6MM X 1/8 PT
FITTING, AIR, STRAIGHT MALE CONNECTOR, 6MM X 1/4 PT
FITTING, AIR, STRAIGHT UNION, 4MM
FITTING, AIR, STRAIGHT UNION, 6MM
FITTING, AIR, STRAIGHT UNION, 8MM
FITTING, AIR, UNION ELBOW, 6MM
D03 PROPORTIONAL
MA CONTROL / MOTOR SPOOL (A/B TO T)
FAJ
Valve body, hydraulic, aluminum, 90-deg, T-10A, SAE 8
25 GPM
Valve body, hydraulic, steel , 90-deg, T-10A, SAE 8
25 GPM
METAL FILLER BREATHER
Fully adjustable pressure compensated flow control valve with reverse flow check
Capacity 6 gpm | Cavity T-13A
.1 - 6 gpm
Fully adjustable pressure compensated flow control valve with reverse flow check
Capacity: 12 gpm | Cavity: T-5A
#12SAE PORT THREADS W/ UNC POST
25 PSI BYPASS / 1-12 UNF FILTER THREAD
FILTER HEAD / 25 PSI BYPASS / 1 1/4 SAE PORTS
1-1/2-16 FILTER THREAD
Filter Transfer Cart Rental
- 1 x Strainer
- 1 x Hydraulic 5um Filter
- 11 GPM Unit
- C/W 1x Filter
PER DAY COST
3/8" NON-WIRE SAE J1527 TYPE A1 FUEL LINE (.78" OD)
FLUSHING SKID RENTAL
PER DAY RENTAL
- 50 HP /575V / 3PH
- 200 GAL TANK
- 107 GPM @500 PSI
- RETURN FILTER 2.5 CD 61 INLET
- MANUAL CONTROL
- PRESSURE FILTER X 1
PLEASE NOTE DOES NOT INCLUDE EXTRA FILTERS
UNIT WILL COME WITH 1 FILTER EACH
COMMSION AND DECOMMISON FEES WILL APPLY
COMISSON AND DECOMISSION OF FLUSHING SKID
Meter Type: Basic in Line
Flow Range: 2-25 GPM
Body Material: ALUMINUM
Ports: #12 SAE
Pressure Rating: 3500 psig
Meter Type: Basic in Line
Flow Range: 0.5-5.0 GPM
Body Material: ALUMINUM
Ports: #12 SAE
Pressure Rating: 3500 psig
Filtration Recommended: 74 micron
Meter Type: Basic in Line
Flow Range: 3-30 GPM
Body Material: ALUMINUM
Ports: #16 SAE
Pressure Rating: 3500 psig
Meter Type: Basic in Line
Flow Range: 5-50 GPM
Body Material: ALUMINUM
Ports: #16 SAE
Pressure Rating: 3500 psig
Meter Type: Basic in Line
Flow Range: 1-15 GPM
Body Material: ALUMINUM
Ports: #8 SAE
Pressure Rating: 3500 psig
CLEARVIEW FLOW METER | 3/4" NPTF | 15 GPM | 325 PSI MAX
CROSS PORT W/ MAKE UP CHECKS
SAE 8 PORTS / T-10A
PRESSURE FILTER, 6090 PSI, 15 GPM, SAE-12, BYPASS
87 PSI, 12 MICRONS B=1000
PRESSURE FILTER, 6090 PSI, 74 GPM, SAE-20, BYPASS,
87 PSI, 12 MICRONS B=1000
1/2"BRASS BALL VALVE-FULL PORT
3/4"BRASS BALL VALVE-FULL PORT
